Hyking Excavator Breaker Attachment 2200 Kg Two Stage Planetary Reducer Hydraulic Pump

Dongguan Hyking Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Hyking Excavator Breaker Attachment 2200 Kg Two Stage Planetary Reducer Hydraulic Pump

  • 1
  • 2

Brand Name : HYKING

Model Number : HK-DMB300

Certification : CE,ISO

Place of Origin : China

MOQ : 1 Set

Price : USD15000

Payment Terms : L/C,T/T

Supply Ability : 10 sets per month

Delivery Time : 30 days

Packaging Details : film

Name : Excavator Demolition Attachments

Brand : Hyking

Main Body Material : Hardox450

Jaw Material : 80mm Thick Hardox450

Weight : 2200 Kg

Contact Now

Hyking Excavator Breaker Attachment 2200 Kg Two Stage Planetary Reducer Hydraulic Pump

Specification:

Excavator tonnage 20~40 ton
Self Weight 2200 kg
Max Open 980 mm
Max cutting force 2250 KN
Rotate 360 degree
Oil flow needed for cutting 190~260L/min
Oil flow needed for rotating 20L/min
Main body material Hardox450
Jaw material 80mm thick Hardox450
Blade 2pcs 4 side blade
Rotate motor two stage planetary reducer hydraulic pump

Description:

Hydraulic demolition shears also called demolition crusher,multi-processor,etc.It’s composed with main body, hydraulic cylinder, movable jaw . The external hydraulic system offer hydraulic pressure for the hydraulic cylinder to make the two movable jaws open and close to achieve the effect of crushing concreted walls.Mainly function is for both primary and secondary demolition work.

It’s low noise, no vibration, meet the requirements of environmental protection, which are Suitable for city and high-tech zone demolition project.

Our Demoliton crusher shear have follow advantages:

1. Both the main-body and jaws are made from hardox450,structure is high performance

2. The 2pcs jaws is made from 80mm thick hardox450 steel,much more longer life than cast jaw.

3. We use boring machine adjust the precision after welding,to avoid the big tolerance leaded by welding

stress.

4. Blade is 2pcs 4-side blade,so have a much more longer life

5. The blade of this demolition shear,can cut 30mm-diameter steel rod,can cut 30mm-thick steel sheet.

6. Rotate motor is two stage planetary reducer hydraulic pump,much more higher rotate speed,better than worm gear pump.

7. Hydraulic oil cylinder is equipped with a protective cover to obstruct the splash of concrete and

steel debris.

8. The grease injection nipples have cover protected,won’t be damaged in rough demolition work.

Application:

1. Demolishing buildings

2. Demolition which need lower noise.
